ZASTOSOWANIE:

CASE:

AVJ55, AVJ60, AVJ70, JX1060V, JX1070N, JX1070V, JX1075N, JX1075V, JX1095N, JX1095V, VJ60, VJ70, VJ80


FIAT:

55-46, 55-46DT, 60-46, 60-46DT, 65-46, 65-46DT, 55-56, 55-56DT, 65-56, 65-56DT, 70-56DT, 70-56L, 45-66, 45-66DT, 45-66V, 50-66, 50-66DT, 50-66S, 55-66, 55-66DT LP, 60-66, 60-66DT, 70-66, 70-66DT, 70-66F, 70-66LP, 80-66, 80-66DT, 80-66F, 55-76F, 55-76FDT, 55-76V, 55-76VDT, 60-76F, 60-76FDT, 70-76DT, 70-76F, 70-76LP, 70-76V, 55-86F, 55-86FDT, 55-86V, 55-86VDT, 60-86F, 60-86FDT, 60-86V, 60-86VDT, 82-86DT, 82-86F, 82-86LP, 55-88, 55-88DT, 60-88, 60-88DT, 65-88, 65-88DT, 70-88, 70-88DT, 80-88, 80-88DT, 100-90, 100-90DT, 110-90, 110-90DT, 55-90, 55-90 DT, 60-90, 65-90, 65-90DT, 70-90, 70-90DT, 80-90, 80-90DT, 85-90, 85-90DT, 90-90, 90-90DT, 60-93, 60-93DT, 65-93, 65-93DT, 72-93, 72-93DT, 82-93, 82-93DT, 60-94, 65-94, 65-94DT, 72-94, 72-94DT, 82-94, 82-94DT, 350DT, 466, 466DT, 500DT, 566, 570, 580, 650, 666, 670, 680, 750, 766, 780, 880, 980, F100Dal, F100Fino, F110, F115, F120, F130, F140



WYMIARY(mm):
- stożek = 16-18 mm

- długość = 80 mm

- gwint zewnętrzny = M20 x 1

NR KATALOGOWY: 4954941, 4987961, 5109526
